400mm Width Material Servo Roll Feeder with Pneumatic Releasing System

Product Categories
Dongguan Qiaosen Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

400mm Width Material Servo Roll Feeder with Pneumatic Releasing System

Price : $3,800/cases 1-2 cases

MOQ : 1

Payment Terms : T/T

Supply Ability : 1set 7days

place of origin : Guangdong, China

type : Feeder Machine

use : Sheet

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Engine, Bearing, Motor

brand name : Qiaosen

voltage : 380

power(w) : 1500

warranty : 1 Year

key selling points : Easy To Operate

weight (kg) : 200

Feeding Speed : 15 m/min

Item name : Pneumatic & Mechanical Feeding Straightening feeder

Keyword : Straightening feeder

Width of material : 400mm

Thickness of material : Max 3.2mm

Feeding capacity : 300W*2.3T

Feeding length : 0.01-9999.99mm

Roll pressure : Spring type

Releasing system : Pneumatic type

Pass line adjustment : 50mm

Power supply : AC380V/3phase

Place of Origin : China

Brand Name : QIAOSEN

Certification : CE / ISO14001

Contact Now

Mechanical Precision Servo Roll Feeder
Servo Roller Feeder Punching Press Automatic Pneumatic & Mechanical Feeding Straightening feeder
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Product Specifications
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
NC-400B NC Servo Roller Feeder
  • Feeds material for various thicknesses and feeding stroke lengths
  • Suitable for high-speed feeding and long stroke length feeding
  • Improves production capacity and feeding precision
  • User-friendly operation panel for inputting feeding length and speed
  • Feeding length range: 0.01mm - 9999.99mm
  • Adopts pneumatic cylinder releasing method, without malfunction
  • Mechanical releasing method available per customer requirements
  • High precision feeding: ±0.02mm
  • Supports 5 sets of different feeding lengths with 999 strokes each
  • Normal manual running mode with manual speed for easy material feeding
  • Effective releasing device based on press machine's cam position and material thickness
  • Touch screen input for feeding length
  • Hollow feeding roller with HRC60 surface hardness and chrome plating
Structural Features
  • High-quality servo motor for efficient feeding testing
  • High-sensitivity encoder for feedback and improved feeding precision
  • Quality belt system to avoid gear gaps, abrasion, noise, and lubrication needs
  • Internally mounted motor for protection against damage
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Similar Products
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Company Profile

Dongguan Qiaosen Machinery Co., Ltd operates its own factory in Jiangsu province, established in 2016. Located near Shanghai city with convenient transportation, our facility is a hub of creative minds and gifted talents.

Our factory was among the first to pass ISO9001:2008 quality management system certification. We specialize in hydraulic press machine production, offering 10-ton to 2000-ton press machines across 8 series with over 100 types. Our product range includes single column, four column, C-frame, H-frame presses, punching machines, folding machines, and cutting machines.

Our equipment serves various industries including aviation, aerospace, automotive, shipbuilding, light appliances, and daily hardware. Our products are recognized for exquisite design, competitive pricing, excellent quality, efficient after-sales service, and technical support.

We serve customers across more than 20 domestic provinces and export to the United States, Japan, Russia, European Union, Southeast Asia, the Middle East, and other countries.

400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Product Packaging
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System 400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
